Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert

Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert
Flat corrugated galvanised sheets 1.2mm Thickness JIS G3302 SGCC Zinc Coated Hot Dipped
Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert

Image Grand :  Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert

Détails sur le produit:
Lieu d'origine: Jiangsu, Chine
Nom de marque: JIANGSU LIANZHONG
Certification: ISO, SGS, ROHS
Model Number: DX51D, DX52D, DX53D, DX54D, Q195-Q345
Conditions de paiement et expédition:
Quantité de commande min: 1 tonne
Prix: negotiable
Packaging Details: Standard Waterproof Package
Délai de livraison: 7 à 15 jours
Payment Terms: TT/LC/Western Union
Supply Ability: 5000 Tons/Month

Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert

description de
MOQ: 1 TON Standard: GB, ASTM, JIS
Product Name: Galvanized Steel Sheet Coil ID: 508 610mm
Spangle Type: Regular Spangle Package: Standard exporting package
Délai de négociation: Les États membres doivent fournir aux autorités douanières compétentes les informations suivantes:
Mettre en évidence:

1.2mm a galvanisé la tôle d'acier

,

Plaques galvanisées ondulées à chaud

,

JIS G3302 a galvanisé la tôle d'acier

Galvanized Steel Sheet Flat Corrugated 1.2mm Thickness JIS G3302 SGCC Zinc Coated Hot Dipped

Product Description:



Galvanized patterned sheet is a beautiful, easy to process, and cost-effective sheet material suitable for different construction parties and industry needs. Its pattern has anti slip effect and good strengthening performance, which can save steel and ensure cost-effectiveness. Wide application range, suitable for industries such as transportation, construction, decoration, mechanical manufacturing, shipbuilding, etc



Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 0



Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 1

Surface:


Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 2Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 3



Technical Parameters:


l
Technical Standard
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653


Steel Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD,
S550GD; SGCC, SGHC, SGCH, SGH340, SGH400,SGH440,SGH490,SGH540,
SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230),
SQ CR22 (255), SQ CR40 (275), SQ CR50 (340),SQ CR80(550), CQ, FS, DDS,
EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340),
SQ CR80 (550); or Customer’s Requirement
Type
Coil/Sheet/Plate/Strip
Thickness
0.12-6.00mm,or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm
Coil Weight
3-20 metric ton per coil
Package
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer
packing , side guard plate,then wrapped by seven steel belt.or according to
customer's requirement
Export market
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America,
North America, etc

Applications:



Galvanized Steel Sheet is a hot dipped steel sheet with excellent construction material, roofing, and appliance material. It has high tensile strength ranging from 270-500 MPa and is highly durable and corrosion resistant. With a thickness ranging from 0.3 to 3mm, this galvanized steel sheet is ideal for automobile, construction, and appliance industries. It is available in DX51D, DX52D, DX53D, DX54D, and Q195-Q345 models. The minimum order quantity is 1 ton, and the packaging is done with standard waterproof packaging. The delivery time is 7-15 days, and the payment terms are TT/LC/Western Union.



Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 4

Process:



GI sheet zero spangle z100 zinc coated steel sheet 26 gauge galvanized steel sheet





Support and Services:



Plaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 6



Packing and Shipping:



Galvanized steel sheet is packaged and shipped in sheets or coils in accordance with customer requirements. The sheets are usually wrapped in plastic film and then strapped around the outside with metal bands. The coils are usually placed on wooden pallets or steel trays and then strapped around the outside with metal bands.

When shipping galvanized steel sheets, it is important to use the correct packaging. The sheets should be protected from physical damage and moisture during shipping. The packaging should also be able to withstand long-term exposure to the elements.

The packaging materials should be selected according to the size and weight of the sheets. The size and weight of the sheets should also be taken into account when determining how much packaging material is needed.



SGCC SGCD SGCH Galvanised Steel Sheet DX51D DX52D Galvalume Galvanized Steel Sheet Hot Dip Galvanized Steel Plate Price CheapPlaques galvanisées ondulées plates épaisseur 1,2 mm JIS G3302 SGCC Zinc recouvert 8



FAQ:



Q: How to get samples?

A: The catalog and most samples have been prepared for you. It takes about 5-7 days for customized samples. Please contact us for more support.



Q: What is the minimum order quantity?

A: If you want to order a small number of orders or trial orders, please feel free to contact us, we can meet your requirements.



Q: Can you OEM or ODM?

A: Yes, we have a strong development team. Products can be produced according to your requirements.



Q: How long can you guarantee this product/complete?

A: The color is guaranteed for more than 10 years. The quality certificate of the original materials can be provided.



Q: Which payment method do you accept?

A: We accept payment by wire transfer or letter of credit. In addition, you can also transfer money to our bank account, Western Union or PayPal.



Q: What is the average delivery time?

A: For samples, the delivery time is about 5-7 days. For mass production, the delivery time is 10-25 days. In any case, we will try our best to meet your needs.
